Rayonix detectors are in use at several XFEL facilities. The data from these high speed detectors have contributed to major scientific results.

X-ray Free Electron Lasers are providing extremely high photon flux in high frequency pulse patterns. Highly specialized X-ray detectors are required to take full advantage of these facilities. Rayonix is the only major commercial detector manufacturer offering detectors that fit XFEL requirements:

· Integrating: Ability to detect X-ray patterns that arrive in extremely short pulses, or instantaneously, without loss of linearity (no count rate limitation)

· High dynamic range (at least 60,000 8keV X-ray photons/pixel full well)

· High quantum efficiency for hard X-rays (> 90% at 8keV)

· High frame rates (100Hz and faster)

· Low noise

· High spatial resolution, adjustable pixel size

· Large, seamless area detectors (no gaps in imaging area)

· Custom geometries: Many available sizes and custom geometries such as a tunnel through the center

· External triggering options for syncing detector to the experiment

· Permanent factory calibration eliminates the need for complicated post-refinement of detector parameters

· Support: Fast response and attention to keep your experiment going
